Серводвигун MPL, 460V, 115mm, 76.2mm, 5000rpm, Inc.Encoder, IP66, No Brake, IEC Metric, Free Mounting Holes, Allen-Bradley Код:
MPL-B430P-HJ72AA
Прайсова ціна (за курсом НБУ) (indicative)
Виробник
:
|
Наявність на європейському складі (доставка 1 тиждень):
21 days
|
Вага:
6.631 kg/шт
|
об'єм:
0.0154 m3/шт
|
|
|
|
|
Servo Motor, 460V, 115mm, 76.2mm, 5000rpm, Inc.Encoder, IP66, no brake, IEC Metric, Allen-Bradley
MP-Series™ Low-Inertia Motors
The Allen-Bradley® MP-Series Low-Inertia, high-output brushless servo motors use innovative design characteristics to reduce motor size while delivering significantly higher torque. These compact and highly dynamic brushless servo motors from Rockwell Automation are designed to meet the demanding requirements of high-performance motion systems. This series of servo motors is typically used with the Allen-Bradley Kinetix® 6000, Kinetix 6200, Kinetix 6500, Kinetix 300, and Kinetix 350 servo drive families. Available in nine frame sizes, these motors provide continuous stall torque from 0.26 to 163 Nm (2.3-1440 lb-in.) and peak torque from 0.77 to 278 Nm (6.8-2460 lb-in.)
MP-Series Low-Inertia Motors Provide:
Innovative winding technology yields up to 40% higher torque per unit size than conventional servo motors
Improved winding insulation material for enhanced thermal management and heat transfer, resulting in higher performance
High-energy rare-earth magnets for quicker acceleration
New SpeedTEC DIN connectors allow flexible orientation of connectors and use of a single cable family with all MP-Series motors
Integral 24-volt brake option
Broad torque range – all within one motor family
Optional Shaft Seal for IP 66 environmental rating
Standard IEC 72-1 mounting dimensions
Operating temperature range: 0 - 40° C (32 - 104° F)
The MP-Series Low-Inertia Motors are UL recognized components to applicable UL and CSA standards and CE marked for all applicable directives
High-Performance Feedback
MP-Series Low-Inertia motors are available with high performance encoders with a choice of single-turn or multi-turn high-resolution feedback.
Up to 2 million counts per revolution for smooth performance and precise control (MPL-A/B3xx, -A/B4xx, -A/B45xx, -A/B5xx, -B6xx, -B8xx, and -B9xx motors)
Up to 260 thousand counts per revolution for smooth performance and precise control (MPL-A/B15xx and -A/B2xx motors)
Multi-turn encoder provides high-resolution absolute position feedback within 4096 turns. The electromechanical design does not require a battery
MP-Series servo motors with high resolution encoders may be used as a component of the Kinetix safe-off feature
Smart Motor Technology
On-board memory retains motor identity
Communication link automatically reports identity to the system upon startup for reduced commissioning time
|
|
|
|
