Multigate LMC-14 IP54 RAL7035

LMC 14 LMC 14 MULTIGATE WILL LEAD THROUGH AND SEAL CABLES AS FOLLOWS: 24-54 mm 2 pc 14-22 mm 3 pcs 14-18 mm 4 pcs 10-14 mm 5 pcs Total 14 pcs		Multigates are metal or plastic reinforced cable gland plates for leading through both low and medium power current cables as well as various types of tubing. The products fit directly to B- och C-standard aparture (FL13 or FL21). Multigates do not need any separate gaskets or glands which makes Multigates very easy to use, providing innumerable advantages in a single assembly unit. Multigate cable gland plates are made of various type of polymers. All these polymers are RoHS approved and have excellent weather, UV- and ozone resistance. Also EMC-compatible and oil resistant models are available. Oil resistancy has been tested according to UL 157-standard, and these test resultat are available on request. Multigates are possible to supply with plastic locking pins, which can be used to secure the Multigate to metal as well as plastic enclosures (indoor application). LMC 14 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard aperture (or FL21).   LMC 14 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. LMC 14 Multigate is suitable for both outdoor and indoor applications.
